Bunk Houses Container

NAME OF MATERIAL

DIFFERENT TYPES AVAILABLE

Internal Insulation - 50mm/75mm/100mm

Glass wool/Rockwool/PUF Polyurethane/ PIR - Polyisocyanurate /Fiberglass/EPS Board/Thermocol

Wall Paneling Or Room Finish

PPGI Panels/Wooden Panels/PVC Panels/Aluminum Composite Panel/Plaster Of Paris with calcium silicate board/ Gypsum Board/ pre laminated MDF/ Wall tiles/ Wallpaper

Roof Paneling Or Roof Finish

PPGI panels/False Ceiling/Grid Ceiling/Wooden Panels/PVC Panels/Aluminum Composite Panel/ Plaster Of Paris  with calcium silicate board/ Gypsum Board/  pre laminated MDF/ Wallpaper

Flooring

Vinyl/Ceramic Tiles/Marble/ Wooden/Antiskid/ Rubber Tiles/ Chequer Sheet (Aluminum/Mild Steel/Stainless Steel)

Wiring

All Electrical Item Of

ISI Standards

All wiring shall be concealed and shall be PVC insulated copper Wires of ISI quality (Make Havells), suitable for 240 volt, 50 HZ single phase AC Power supply. 2.5 mm thick cable for lighting, 5 amp switches & Socket & 15 Amp Socket, 2.5 mm thick cable for main electrical supply & with MCB protection With A.C. Provision.

Lighting

Cove Lights/Led Lights/Tube Lights/Grid Light

Power Plugs And Sockets

2.5/5/10/13/15/16/20 Amps And Even More

Connectors

Intercom/Internet/Ethernet

Circuit Breaker

MCB/RCCB/ELCB/RCBO

Air conditioner 1T/1.5T/2T

Split/Window/Portable(Voltas/ Hitachi/Diaken/ Ogeneral)

Furniture/Furnishing

Workstations

Wooden/PVC Finish  Size: 4x18 with Keyboard Drawer and Power Panel

Table

Marble Top/Wooden Top/Glass Top Table/PVC Table

Conference Table

Marble Top/Wooden Top/Glass Top Table/PVC Table

SIZES 10x3 10 Seater,

               12x3 12 Seater,

               20x3 20 Seater,

               35x3 30 Seater,

Customizable sizes are available as per requirement

Chairs

Executive/High-End

Sofa

Sofa

Storage Compartments

Overhead/ Full Height Almirah/ Wardrobe/ L-Type Understorage

Door

Wooden/PVC/

Window

UPVC/Aluminum Sliding or Fixed window

Paint

Red Oxide/Epoxy/Zinc rich Primer and double coated Enamel/PU/Epoxy Paint for MS Finish with 120 DFT(u). Under structure Zinc Rich 40 and bitumen Black 180 DFT (u)

Toilet Accessories

1. EWC (Make Parryware/Hindware/Eros)

2. Washbasin (Make Parryware/Hindware/Eros)

3. Shower (Make Parryware/Hindware/Eros)

4. Urinals (Make Parryware/Hindware/Eros)

CONTAINER STRUCTURAL SPECIFICATIONS

Exterior panelling

Mild Steel Corrugated Sheets 2mm/1.6mm/1.2 mm thick or CORTEN A  corrugated profile.

Base frame

4.5 MM thick mild steel sheet profiled 2 nos of side bottom rail made of IS2062, The cross members are made of pressed channel section Mild Steel 4 MM IS2062. The cross members are placed to fully withstand floor strength and welded to each bottom side rail. 28 MM/ 18 MM Marine ply mounted/screwed on cross members and Fork Pocket Upper 3MM & lower 6MM

Corner post

6 MM thick mild steel sheet pressed section with inner 12 MM thick C channel continuously welded from the inside to provide extra bracing for Rear post only.

Top frame & Roof

60x60x3 mm thick hollow section rectangular tube. With 2 MM Roof panel die stamped made of MS to assist in water drainage. Self draining roof made of MS IS2062, having upward smooth chamber for rain water drainage.

Corner hook

As per ISO 1161 Corner Casting 8 Nos. in the container for lifting.

Door

Constructed of Rigid Steel Frame work by 96mm X 48mm X 3.2 mm (thick) Hollow pipe and horizontal 3mm MS sheet profile section bend. external wall made by Panels 1.6 MM thick MS & Inner wall decorated by 4 mm ACP sheet with suitable door handles, automatic door closer and aldrope, for small doors (6'6"'x3')

Double Door

Double Door as per ISO 1496 Constructed of MS Frame work by 96mm X 48mm X 3.2 mm (thick) Hollow pipe and horizontal 3mm MS sheet profile section bend. Shutter made by 1.6 MM thick MS & for small doors (6'6"'x3') Inner wall panelling with 4 mm ACP sheet with suitable door handles, automatic door closer and aldrope as per ISO 1496

Ladder & hand railing

: Verticle support ISA 75x75x5MM, bracing with ISA 50x50x5MM, Step ISA 25x25x4MM, Flat 20x4mm, Landing Beam ISA 50x50x5mm, with step side angle ISA 75x75x5mm. Riser 7 & Treads 12 and Landing depth 36 & stairway depth 36. Handrailing vertical support  MS Hollow Pipe sections 32mm dia, Top horizontal  MS Hollow Pipe sections 32mm dia  & Middle horizontal  MS Hollow Pipe sections 25mm dia. Treads with 4mm MS chequered sheet.
